Product Type
Vent Motor
Wadsworth M-1190 VC2000 ILS 1 3/8" OD Shaft No Control
Take advantage of Wadsworth’s 40 plus years of experience in automating vents. Wadsworth drive units set the standard for powerful performance, smooth operation and reliability.
- Gear motor: 1/5 HP – 115V; 60Hz; 2.5amps – TEFC+
- Ball bearing motor with copper windings – Class B insulation
- Gear reducer: total reduction 1350:1; 1.2 and 3 RPM final output
- Output torque 1500 inch lb / 169 Nm
- Lifts up to 325’ of 4’ polycarbonate roof ridge vent or 400’ of 4’ polycarbonate side vent
This product will be shipped directly from the manufacturer and freight charges are additional.
