Product Type
Vent Motor
Wadsworth M-1090 VC100A/ILS Drive Unit 1 3/8 OD Shaft
Take advantage of Wadsworth’s 40 plus years of experience in automating vents. Wadsworth drive units set the standard for powerful performance, smooth operation and reliability.
- Gear motor: 1/20 HP – 115V; 60Hz; 0.68 amps – TENV
- Ball bearing motor with copper windings – Class B insulation
- Gear reducer: total gear reduction 1900:1; 0.85 and 2.5 RPM final output
- Output torque 500 inch lb / 56 Nm
- Lifts up to 75’ of 4’ polycarbonate roof ridge vent or 125’ of 4’ polycarbonate side vent
This product will be shipped directly from the manufacturer and freight charges are additional.
